Xmas In Wall Tank Thread

[Dace]

hammerhead that could be a little to big, if you are going to tee it off to run other equipment.I have a 265g with two 2inch hole in the back of my tank the pump i use is barracuda and that match my water flow going down in the sump. I rather have more water movement in the tank then the system.If you going to run a big pump then your sump should be real big

My sump will be 5' x 30" x 20"



[manyfish]

good size sump, my is 5f,18in,22in



[autoponicz]

this is gonna be one fun adventure......goodluck



[cali_reef]

Return on Hammerhead after head pressure 3800 gph

An overflow length of 36" @ 1" tall will not handle 3,800 GPH.

http://www.reefcentral.com/calc/drain.php?gph=3800&drain=Submit

2,000 GPH would be the most I would put thru this size overflow, you need a little safety margin in there.



[Dace]

thank you Cali. With all the head room between my basement and display i will adjust accordingly. will tee of pump if necessary to fee skimmer.also pump will have a ballvalve incase i need to turn it down a bit

An overflow length of 36" @ 1" tall will not handle 3,800 GPH.

http://www.reefcentral.com/calc/drain.php?gph=3800&drain=Submit

2,000 GPH would be the most I would put thru this size overflow, you need a little safety margin in there.



[Dace]

Here is my new 180gal tub getting my marco rock ready for my feb XMAS tank up grade.



[Tonyscoots84]

:teeth:



[Dace]

Equipment

Xmas In Wall Tank Thread
<HR style="COLOR: #132435" SIZE=1><!-- / icon and title --><!-- message -->I am starting this thread to get input on my after Xmas tank setup. This setup will probably start the first week on Feb. 2008.

First the tank.
This will be a Glass Cage tank dimension's 80"wide x 36"deep x 30"high. This tank will be in wall, will have a 8" overflo on the left side of tank. So the overflo will be 8"wide x 36"deep x 30"high. tank will have 1 x 2" drain and 2 x 1" returns. with all other 3 panes Starphire Glass.

Lighting.
I will be using 3 lumenarcs3
Aquarium Specialty
#x Pfo 400 watt HQI Ballast to overdrive the bulbs .Bulbs will be 400watt SE 20k Radium Bulbs
also will have 3 PFO Mogul mounted Moon lights.
PFO 1Watt Extreme LED Moon Light - mogule mount: Premium Aquatics
Supplement lighting will be 4 VHO actinic 72" Ice Cap Retro Kit
2x 72" VHO URI Aquasun
2x 72" VHO URI Super Actinic R
Champion Lighting & Supply :: Lighting :: VHO Fluorescent :: IceCap VHO Retros :: 4x72" Ice Cap Retro W/2-430

Water Movement
2x Vortech Pumps
EcoTech Marine VorTech Propeller Pump w/wireless controller: Premium Aquatics
2x Wavy Sea
WavySea **PLUS** Ocean Simulation - Black Model: Premium Aquatics
On a closed loop Reef Dart
Sequence ReefFlo Dart Water Pump 3600gph: Premium Aquatics
and the return from basement Sequence Hammerhead
Sequence ReefFlo HammerHead Water Pump 5800gph: Premium Aquatics

Filtration.
About a 6" sand bed
About 400lbs of rock including sump
and a Deltec 902 skimmer
Deltec - Aquarium Equipment - protein skimmers, turbo skimmers, calcium reactors, fluidized reactors, kalkwasser stirrers

All Other Equipment Used With Setup
Deltec Calcium Reactor
Deltec - Aquarium Equipment - protein skimmers, turbo skimmers, calcium reactors, fluidized reactors, kalkwasser stirrers
Deltec Kalk Reactor
Deltec - Aquarium Equipment - protein skimmers, turbo skimmers, calcium reactors, fluidized reactors, kalkwasser stirrers
Deltec Fluidized Chamber
Deltec - Aquarium Equipment - protein skimmers, turbo skimmers, calcium reactors, fluidized reactors, kalkwasser stirrers
Phosban Raector
TLF PhosBan Reactor 150 - no pump: Premium Aquatics
Carbon Reactor
My Reef Creations--New Products
Litermeter 3
Untitled Document
Rodi System
Untitled Document
Redsea Ozonizer
http://www.marinedepot.com/ps_ViewIt...ct~RS3675.html
3x Heaters
Eheim-JAGER TS Heater - 250 watt: Premium Aquatics
Rock Work By
Home
Sump.
60"Width x 30"Deep x 20"High
Reef Sump By NY Acrylics

Please free to chime in on any advice you feel will be helpfull to this setup.

David



[NYreefNoob]

dave just lmk when your ready. also i dont think you can run that much flow through the wavy sea's. and thats alot of return flow, making the flow though your sump awful fast for it to really to be getting the benifit's. also once it's switched you going to use the black tub for a dsb ?



[Davidl919]

Ok that's a Lot of work. I'll sleep over Saturday night to Sunday to help, Are you going to need any 1 inch I still have about 5ft rigid and 5ft flex also Dont buy the clear primer I've got more than enough of that... Get the Basement bed ready. Ah man all that glue. :cheers:



[Dace]

Ok that's a Lot of work. I'll sleep over Saturday night to Sunday to help, Are you going to need any 1 inch I still have about 5ft rigid and 5ft flex also Dont buy the clear primer I've got more than enough of that... Get the Basement bed ready. Ah man all that glue. :cheers:

Dude you know you won't be in the basement.........but the chimney will suit you fine....:biggrin:



[Dace]

dave just lmk when your ready. also i dont think you can run that much flow through the wavy sea's. and thats alot of return flow, making the flow though your sump awful fast for it to really to be getting the benifit's. also once it's switched you going to use the black tub for a dsb ?

Rick each wavy sea Plus can handle 3600gph and the regular one can handle 2300 and i'm using a reefflo dart which is about 3600gph on two wavysea's that handle 2300 so i should be fine, as for the flow in sump. my new sump was design to be a high flo sump. i will find a way to plumb the skimmer so it will have a slower water turn over rate so it can skim properly.

<TABLE cellSpacing=0 cellPadding=10 width=760 align=center border=0><TBODY><TR bgColor=#ffffff><TD bgColor=#cccccc>What is the maximum GPH for WavySea?</TD></TR><TR bgColor=#ffffff><TD>WavySea is a work of engineering genius. Our tests from over 200 locations have revealed that WavySea can handle maximum of 2,300 GPH (Gallons Per Hour)! But of course, no device should be driven to its max. It should be able to handle just about anything you throw at it! For those that require more flow, WavySea Plus+ can handle up to 3,600 GPH!!!
More about the maximum limit: 2,300 maximum GPH will vary depending on many factors. This includes water condition and even the climate of your residence (due to air pressure).

</TD></TR></TBODY></TABLE>



[NYreefNoob]

i thought they handled alot less than that, like the seaswirls. if this tank turns out anything like the one have now it will be awesome



[frank arriaga]

Dave,if I can help with anything lets me know. I just put back the two 6100 tunze for more flow the 3 dart just wasn't enough. good luck



[Dace]

Dave,if I can help with anything lets me know. I just put back the two 6100 tunze for more flow the 3 dart just wasn't enough. good luck

I really need to take the time and come over and check your setup out. plus i really need to talk to you for my future setup :grouphug:



[Tim]

Sounds great,where`s the Chiller?



[kimoyo]

Yeah, I got a question. Whats up with quaratine?



[Dace]

Sounds great,where`s the Chiller?

in the basement. :shhh: he's hibernating now :teeth:



[Dace]

Yeah, I got a question. Whats up with quaratine?

what about it...:scratch:



[cali_reef]

Yeah, I got a question. Whats up with quaratine?

I think he should buy my 300G as a QT setup.:idea:
